• 25mm and 28mm width carbon rims optional
• High cost performance DT Swiss 350s rim-brake hub
• Shimano/Sram 11-12 speed freehub available
• Pillar 1423 spokes, aero and strong
• Compatible for 700*25C-45C tire (tubeless ready)
Item NO.:
350S Clincher WheelsPayment:
Paypal, Bank TransferOrigin:
ChinaColor:
UD/3K/12K(Customized Decal Acceptable):
ProX DT350 Carbon Road Wheels - Mid-to-high End Carbon Wheels For Training and Racing
DT Swiss 350s road hubs are developed to be reliable and simplified. The reliability is achieved by the simultaneous engagement of the ratchets which result in larger contact area.
The simplified end-caps design makes it possible for tool-free disassembly and easy maintenance. The cost of DT350 hubs are much lower than DT240 and DT180 hubs.
Carbon road wheelsets built with DT350 hubs are of great performance and affordable price for training or amateur racing.
ProX provides two width option for our DT350 rim-brake carbon wheels. That is, 28mm width carbon clincher rims, and 25mm width carbon rims clincher.
Both series rims are with high TG 3K grooved braking track, which provides more friction, shorten about 30% braking distance, faster heat elimination.
The 28mm width rim series (model PRV28) is with 28mm outer (21mm inner) width.
For such wide road rims, the optimized aerodynamics tire size is 700*28C. If you plan to use 28C (or wider) tire, PRV28 rim series is recommended.
The 25mm width rim series (model PRV25) is with 25mm outer (18mm inner) width.
For such wide road rims, the optimized aerodynamics tire size is 700*25C. If you plan to use 25C tire, PRV25 rim series is recommended.
ProX Mid-to-high End DT350 Rim Brake Carbon Road Wheelset Specification:
-Hub:DT350 Road (front 5*100mm QR/rear 5*130mm QR)
-Brake type: rim brake/non-disc
-Cassette Body: Shimano 11s or Sram 12s XDR optional
-Freehub System: Ratchet System 36 SL
-Type: straight pull
-Spoke Hole Count: front 20H/rear 24H
-Tire Type:Clincher/tubeless ready
-Spoke: Pillar 1423
-Spoke Tension(recommended): ≤130kgf
-Tire Pressure: 125psi/8.6bar
-Warranty Year: 2 years
DT350 Rim-brake Carbon Clincher Wheels Built With 28mm Width Rims
Model
Rim
Depth
Outer Width
Tire Type
Hub
Front Size
Rear Size
Spoke
350S-PRV28-33C-1423
PRV28-33C
33mm
28mm
Tubeless or Clincher
DT350S Road
5*100mm QR
5*130mm QR
Pillar 1423
700*28C-45C
1602g
350S-PRV28-38C-1423
PRV28-38C
38mm
28mm
Tubeless or Clincher
DT350S Road
5*100mm QR
5*130mm QR
Pillar 1423
700*28C-45C
1622g
350S-PRV28-44C-1423
PRV28-44C
44mm
28mm
Tubeless or Clincher
DT350S Road
5*100mm QR
5*130mm QR
Pillar 1423
700*28C-45C
1642g
350S-PRV28-50C-1423
PRV28-50C
50mm
28mm
Tubeless or Clincher
DT350S Road
5*100mm QR
5*130mm QR
Pillar 1423
700*28C-45C
1702g
350S-PRV28-55C-1423
PRV28-55C
55mm
28mm
Tubeless or Clincher
DT350S Road
5*100mm QR
5*130mm QR
Pillar 1423
700*28C-45C
1742g
700C Rim-brake Carbon Clincher Rims 28mm Width
| Rims | PRV28-33C | PRV28-38C | PRV28-44C | PRV28-50C | PRV28-55C |
| Max Weight Limit | 105kg/230lb | 105kg/230lb | 110kg/240lb | 110kg/240lb | 110kg/240lb |
| Material | T700 | T700 | T700 | T700 | T700 |
| Sectional Drawing |
|
|
|
|
|
DT350 Rim-brake Carbon Clincher Wheels Built With 25mm Width Rims
Model
Rim
Depth
Outer Width
Tire Type
Hub
Front Size
Rear Size
Spoke
350S-PRV25-38C-1423
PRV25-38C
38mm
25mm
Tubeless or Clincher
DT350S Road
5*100mm QR
5*130mm QR
Pillar 1423
700*25C-45C
1602g
350S-PRV25-45C-1423
PRV25-45C
45mm
25mm
Tubeless or Clincher
DT350S Road
5*100mm QR
5*130mm QR
Pillar 1423
700*25C-45C
1642g
350S-PRV25-50C-1423
PRV25-50C
50mm
25mm
Tubeless or Clincher
DT350S Road
5*100mm QR
5*130mm QR
Pillar 1423
700*25C-45C
1682g
350S-PRV25-60C-1423
PRV25-60C
60mm
25mm
Tubeless or Clincher
DT350S Road
5*100mm QR
5*130mm QR
Pillar 1423
700*25C-45C
1802g
350S-PRV25-80C-1423
PRV25-80C
80mm
25mm
Tubeless or Clincher
DT350S Road
5*100mm QR
5*130mm QR
Pillar 1423
700*25C-45C
2002g
700C Rim-brake Carbon Clincher Rims 25mm Width
Rims
PRV25-38C
PRV25-45C
PRV25-50C
PRV25-60C
PRV25-80C
Max Weight Limit
110kg/240lb
110kg/240lb
115kg/250lb
120kg/265lb
120kg/265lb
Material
T700
T700
T700
T700
T700
Sectional Drawing
 |
Carbon Fiber Material Premium Toray T700 + T800 carbon fiber are used in our carbon rims. Combining with stable resin system to make consistent quality and light weight road carbon rims.
|
 |
Wider Inner Width
Wider 21mm inner width, optimized for increasingly popular 700x28C tires (also fit even wider tires). Wider stance for tire, easy tire mounting and dismounting. Better traction and cornering performance.
|
 |
Aero U Shape Wide U Shape road carbon rims are more aerodynamic than traditional V Shape road bike rims. It is also of better stiffness and strength. |
 |
Tubeless Ready
Tubeless tire is getting popular in carbon road bike wheelset thanks to its better traction, lower rolling resistance and better riding comfort. All our carbon clincher rims are tubeless ready (also fit normal tube tires). Optimized anti-burp bump design provides easy tire mounting, dismounting, as well as air inflation. |
 |
Rim Brake Road carbon rims designed with high TG brake track for rim brake use. Unique looking small grooves on brake surface. Small grooves provide more friction, shorten braking distance up to 30%. Faster water clearance, better performance in wet condition. Small grooves also help to eliminate braking heat faster, better protect the rim in long descending.
|
 |
Hand Built All our carbon fiber wheelsets are hand built by experienced mechanician. Based on customers’ demand, various choice of hubs, spokes and nipples are optional. After wheel built, they are trued precisely at high standard (≤0.3mm) on roundness, lateral and center tolerance.
|
 |
DT350 Road Hubs DT Swiss 350 road hubs are used. Rim brake carbon wheels with great performance and competitive price. DT Swiss Ratchet System, reliable and stable. Straight pull spoke system, direct power transmission. 5*100/5*130 standard QR, with Shimano 11-speed, Sram 12-speed XDR freehub optional.
|
 |
Pillar Spokes The popular Pillar PSR AERO 1423 spokes are used. Pillar patented cold forge technology is applied in the spoke production which increase the strength up to 20%. Perfect aero shape, high elasticity and low drag coefficient.
|
 |
2-Year Warranty We have strict production management system, QC and Testing process. Our quality is always very good and reliable. For all carbon rims and carbon wheels sold by ProX, 2 years’ quality warranty is offered (starting from the date of package being signed).
Click Warranty Policy to see more details in another page. |
